2 Switch, Mureva Styl, complete product, 1-pole 2-way, electromechanical, 10AX, IP55, grey - MUR35022
DESCRIPTION
| Range: | Mureva Styl |
|---|---|
| Range of product: | Mureva Styl |
| Product or component type: | Switch |
| Category: | Rocker switch |
| Device presentation: | Complete product |
| Technology type: | Electromechanical |
| Number of rocker: | 2 |
| Colour tint: | Grey (RAL 7016) |
| Device mounting: | Surface |
|---|---|
| Switch function: | 1-pole 2-way |
| Actuator: | Rocker |
| Rated current: | 10 AX |
| Load type: | Load for energy saving lamps with ballast: 100 W |
| [Ue] rated operational voltage: | 250 V AC |
| Condition of use: | Indoor/outdoor |
| Material: | SEBSBrassABS (acrylonitrile butadiene-styrene) |
| Fixing mode: | By screws |
| Clamping connection capacity: | 1.5...2.5 mm² for rigid cable(s)1.5...2.5 mm² for stranded cable(s)1.5...2.5 mm² for flexible cable(s) |
| Wire stripping length: | 13 mm |
| Cable entry: | Easy valve access diameter: 6...20 mm |
| Resistance to chemical agents: | Resistant to alcohol (70 %)Resistant to alcohol (96 %)Resistant to A-Lactic AcidResistant to diluted quaternary ammoniumResistant to diluted bleachResistant to diluted ammoniaResistant to soapy waterResistant to crystal cleanerResistant to hydrogen peroxide 10 volumesResistant to hexane |
| Height: | 76 mm |
| Width: | 76 mm |
| Depth: | 64 mm |
| Projecting depth: | 64 mm |
| Quality labels: | CENFAENOREAC |
|---|---|
| IP degree of protection: | IP55 |
| IK degree of protection: | IK08 |
| Flame retardance: | Self-extinguishing 650 °C conforming to IEC 60695-2-1 |
| Standards: | EN 60669-1 |
| Ambient air temperature for operation: | -5...40 °C |
| Ambient air temperature for storage: | -25...55 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606480789236 |
|---|
