Acti9 iID - RCCB - 2P - 63A - 300mA - type A - A9R04263

DESCRIPTION

Standards: EN/IEC 61008-1
IP protection degree:
Pollution degree: 3
Electromagnetic compatibility: Impulse resistance 8/20 µs, 250 A in accordance with EN/IEC 61008-1
Operating temperature: -25?60 °C
Ambient temperature for storage: -40?85 °C
Range: Acti9
Product name: Acti 9 iID
Product or device type: Residual current circuit breaker (RCCB)
Device name: iID
Pole description: 2P
Neutral position: Left
Rated operational current In: 63 A
Network type: AC
Residual sensitivity: 300 mA
Residual protection delay: Instantaneous
Differential protection class: Type A
Device position in installation: Downstream
Network frequency: 50/60 Hz
[Ue] Rated operational voltage: 220...240 V AC 50/60 Hz
Differential technology: Voltage-independent
Rated making and breaking capacity:
Idm: 1500 A Im
Conditional short-circuit current: 10 kA
[Ui] Rated insulation voltage: 500 V AC 50/60 Hz
[Uimp] Rated impulse withstand voltage: 6 kV
Fully visible disconnection: Yes
Control type: Toggle
Mounting mode: Clip-on
Mounting support: DIN rail
9 mm pitch: 4
Height: 91 mm
Width: 36 mm
Depth: 73.5 mm
Product weight: 0.21 kg
Color: White
Mechanical durability: 20000 cycles
Electrical durability:
Optional locking description: Padlock device
Connection type:
Stripping length: 14 mm (top or bottom)
Tightening torque: 3.5 N·m (top or bottom)
AC-1: 15000 cycles
Idm: 1500 A
Im: 1500 A
Code EAN: 3606480091551
