Schneider Electric Acti 9 Acti9 iIL single indicator light - White - 110-230 Vac - A9E18322
Schneider Electric Acti 9 Acti9 iIL single indicator light - White - 110-230 Vac - A9E18322

Acti9 iIL single indicator light - White - 110-230 Vac - A9E18322

SKU : A9E18322

Contact us for price and lead time for this product. Our team will respond quickly.

Lead time: 2–3 weeks – Ships quickly after order confirmation



We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.

Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.

We take great care in packaging and ensure all goods are delivered safely and promptly.

REQUEST A QUOTE
Estimated Delivery : - .

Acti9 iIL single indicator light - White - 110-230 Vac - A9E18322

DESCRIPTION

Range of product: Acti 9
Range: Acti 9
Product name: Acti 9 iIL
Product or component type: Modular pilot ligth
Device short name: IIL
[Us] rated supply voltage: 110...230 V AC at 50/60 Hz110...130 V DC
Local signalling: 1 LED white, service life 100000 h of constant lighting efficiency (consumption 0.3 W)
Mounting mode: Fixed
Mounting support: Symmetrical DIN rail
Comb busbar and distribution block compatibility: Upside: ProDis
9 mm pitches: 2
Height: 82 mm
Width: 18 mm
Depth: 69.5 mm
Colour: White (RAL 9003)
Auxiliary connection terminal: Tunnel type terminal 1 cable(s) rigid 0.5 mm²Tunnel type terminal 2 cable(s) rigid 2.5 mm²Tunnel type terminal 1 cable(s) flexible 0.5 mm²Tunnel type terminal 2 cable(s) flexible 2.5 mm²Tunnel type terminal 2 cable(s) flexible with ferrule 2.5 mm²
Wire stripping length: 9 mm
Tightening torque: 1 N.m
Market segment: Small commercialResidential
Compatibility code: IIL
Standards: IEC 60947-5-1
IP degree of protection: IP2IPxx B
Pollution degree: 3
Tropicalisation: 2
Relative humidity: 95 % at 55 °C
Ambient air temperature for operation: -35...70 °C
Ambient air temperature for storage: -40...80 °C
Sustainable offer status: Green Premium productREACh Regulation
Code EAN: 3606480088346
