Schneider Electric SCHNEIDER plug-in electromechanical relay - 10 mm - 24 V DC - 1 NO - ABR7S21
Schneider Electric SCHNEIDER plug-in electromechanical relay - 10 mm - 24 V DC - 1 NO - ABR7S21

plug-in electromechanical relay - 10 mm - 24 V DC - 1 NO - ABR7S21

SKU : ABR7S21

Contact us for price and lead time for this product. Our team will respond quickly.

Lead time: 2–3 weeks – Ships quickly after order confirmation



We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.

Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.

We take great care in packaging and ensure all goods are delivered safely and promptly.

REQUEST A QUOTE
Estimated Delivery : - .

plug-in electromechanical relay - 10 mm - 24 V DC - 1 NO - ABR7S21

DESCRIPTION

Range of product: Advantys Telefast ABE7
Product or component type: Plug-in electromechanical relay
Control circuit type: DC
Width pitch dimension: 10 mm
Product compatibility: ABE7P16T212ABE7P16T214ABE7P16T210ABE7P16T230EABE7R16T210ABE7R16T212ABE7P16T215ABE7P16T230
[Uc] control circuit voltage: 24 V
[Ith] conventional free air thermal current: 5 A
Contacts type and composition: 1 NO
Threshold tripping voltage: 19.7 V at 40 °C
Drop-out voltage: 2.4 V at 20 °C
Drop-out current: 1 mA at 20 °C
Maximum power dissipation per pole: 0.36 W
Associated fuse rating: 1 A, fast blow
Maximum switching voltage: 130 V DC conforming to IEC 60947-5-1250 V AC 50/60 Hz conforming to IEC 60947-5-1
Electrical durability: 500000 cycles, maximum switching current: 1500 mA at 230 V AC-12500000 cycles, maximum switching current: 1500 mA at 24 V DC-12500000 cycles, maximum switching current: 600 mA at 24 V DC-13 10 ms500000 cycles, maximum switching current: 900 mA at 230 V AC-15
Minimum switching current: 10 mA at >= 5 V
Electrical reliability: 1e-008
Operating rate in Hz: 10 Hz no load0.5 Hz at Ie
Mechanical durability: 20000000 cycles
[Uimp] rated impulse withstand voltage: 2.5 kV conforming to IEC 60947-1
Product weight: 0.008 kg
Max immunity to microbreaks: 5 ms
Dielectric strength: 2000 V conforming to IEC 60947-1
REACh Regulation: Free of Substances of Very High Concern above the thresholdREACh free of SVHC
Code EAN: 3389110644739
